F.2
SEL-734B Capacitor Bank Control Field Reference Guide Date Code 20170207
Accessories
Full-Size Enclosure Accessories
Control Cables
The following cables are three-phase control cables that connect to three
capacitor bank switches. Each cable also connect to a 120 Vac control power
transformer (CPT).
The following control cable connects the SEL-734B enclosure to a Cooper
CCR116K1 junction box.
Combined Sensor
Connector Option
The following accessories are compatible with Full-Size Enclosures using the
combined sensor connector.
Sensor Cables
The following sensor cables connect from the enclosure to three voltage/
current combination sensors.
Commissioning and Testing Cables
Part Number Description
SEL-C543 Cable with 52b feedback. Compatible with 5-pin capacitor bank
switches.
SEL-C544 Cable with 52a/b feedback. Compatible with 6-pin capacitor bank
switches.
SEL-C547 Cable with 52a/b feedback. Compatible with 7-pin capacitor bank
switches.
Part Number Description
SEL-C556 Cable with 52a/b feedback. Compatible with a Cooper CCR116K1
junction box. The SEL-C526 cable can be used to connect the junc-
tion box to an individual switch.
Part Number Description
SEL-C529 Compatible with Lindsey combination sensors.
SEL-C536 Compatible with Piedmont LSCV-SEL model sensors.
Lindsey
9-587/XX/R-22102
a
a
Orderable through Lindsey.
Compatible with Lindsey combination sensors.
Lindsey
R-22748/XX,YY
a
Compatible with Lindsey combination sensors and one Lindsey
neutral current sensor.
Part Number Description
SEL-C545
(Control)
This cable is used to simulate capacitor bank switches. A 19-pin cir-
cular connector connects to the enclosure and insulated banana plugs
connect to the test source.
SEL-C546
(Sensor)
This cable is used to simulate voltage and current sensor signals. A
14-pin circular connector connects to the enclosure and insulated
banana plugs connect to the test source.
