F.3
Date Code 20170207 Field Reference Guide SEL-734B Capacitor Bank Control
Accessories
Full-Size Enclosure Accessories
Security Sleeves
Security sleeves for enclosures with a combined sensor connector shroud a
single cable connection to prevent vandalism. The sleeves are made from
stainless steel. Separate security sleeves are required for each cable (i.e., one
sleeve is required for the control cable, and one sleeve is required for the
sensor cable.)
Individual Sensor
Connector Option
The following accessories are compatible with Full-Size Enclosures using
individual sensor connectors.
Control Cables
The following control cables connect to three capacitor bank switches. The
control power transformer is connected to the enclosure via a different cable.
Sensor Cables
Sensor cables for this enclosure style connect to a single voltage/current
combination sensor. Connect three primary sensors to the enclosure for three-
phase monitoring.
Power Supply/Neutral Sensor Cables
The following cables connect to a neutral current sensor and a 120 Vac CPT.
Part Number Compatible Cables
9250011 SEL-C556, SEL-C529, SEL-C536, SEL-C548
915900311 SEL-C543, SEL-C544, SEL-C547
Part Number Description
SEL-C531 5-Pin switch cable. Compatible with Joslyn VersaVac, ABB PS, and
Cooper VCS switches.
SEL-C537 5-Pin switch cable with 52b feedback. Compatible with Joslyn Ver-
saVac, ABB PS, and Cooper VCS switches.
SEL-C538 6-Pin switch cable with 52a/b feedback. Compatible with Joslyn
VersaVac switches, Cooper NR and NRV oil switches, and Cooper
VCS vacuum switches.
Part Number Description
SEL-C530 Sensor cable for one Lindsey sensor with an ITT Cannon plug.
SEL-C530S Sensor connector shorting plug. Connect to unused sensor
connectors on the cabinet. The plug shorts the connector
pins to prevent unwanted noise on the terminals.
Lindsey 9-587/XX/9-582
a
a
Orderable through Lindsey.
Cable for one Lindsey sensor. Alternative to SEL-C530.
Part Number Description
SEL-C532 Control power and neutral sensor cable. Wires for the neutral sensor
connect to a terminal in the field.
SEL-C539 Control power and Lindsey neutral sensor cable.
