Date Code 20170207 Field Reference Guide SEL-734B Capacitor Bank Control
Section 6
Commissioning
Overview
This section provides tips and instructions to verify that the SEL-734B
Capacitor Bank Control is installed properly and is measuring the power
system correctly.
Front-Panel Menu Structure
Table 6.1 shows the menu options available from the front panel, where you
can view or change settings.
The front-panel terminal test jacks are
for testing only. Do not attempt to
power the device through these test
jacks.
Table 6.1 Front-Panel Menu Structure (Sheet 1 of 2)
Menu Option Submenu Description
Meter Instantaneous Display instantaneous phase and sequence quantities, power fac-
tor, and power.
Crest Factor Display crest factor or reset value.
Max/Min Display Max/Min voltage, current, and power. Reset maximum
and minimum values.
Energy Display energy quantities. Reset energy values.
Demand/Peak Display demand peak quantities.
Harmonics Display THD, K-Factor, and distortion power.
Flicker Display short-term and long-term flicker values.
Transformer Line Losses Display transformer losses and line losses. Refer to the SEL-734
Instruction Manual for details.
Time Of Use Display energy and demand of the present and previous season.
Analog Inputs Display analog inputs.
Events Display Events Display events.
Reset Events Reset events.
Targets Display Device Word bits.
Status Display device status, FID, part number, power supply status,
battery voltage, and operating temperature.
Set/Show Capacitor Controller Settings Display or configure the design template settings. Please refer to
the appropriate design template guide for details.
Meter Settings Set or show the Group 1 settings.
Port Settings Set or show Front Port, Port 1, Port 2, Port 3, or Port 4 settings.
Global Settings Set or show the Global settings.
