6.2
SEL-734B Capacitor Bank Control Field Reference Guide Date Code 20170207
Commissioning
Verify the Measurements
Verify the Measurements
This procedure explains how to check the metered values through different
interfaces.
From the Front Panel
Step 1. Press ENT on the front panel of the SEL-734B.
Step 2. Select
Meter and press ENT.
Step 3. Select
Instantaneous and press ENT.
Step 4. Scroll through the menu to view the instantaneous
measurements.
Using a Terminal
Program
Step 1. Establish communication to the SEL-734B.
Step 2. Click the
ACSELERATOR QuickSet
®
SEL-5030 Software
Terminal icon on the header ribbon or open a terminal program
and establish SEL ASCII communication to the device.
Step 3. Enter Access Level 1.
a. Enter the ACC command.
b. When prompted, enter the ACC password. The default
password is OTTER.
Step 4. Enter the MET command. The SEL-734B will report the
instantaneous voltage, current, and power.
Using QuickSet HMI
Step 1. Open the QuickSet HMI.
Step 2. Navigate to the Instantaneous window. The SEL-734B will
report the instantaneous voltage, current, and power.
From the Front
Terminal
Use a handheld volt meter connected to the front terminal test jacks to test the
voltage.
Front Panel Settings Set or show front-panel settings.
Date/Time Set or show the date and time.
Set Password Set Access Level E and Access Level 2 passwords.
Table 6.1 Front-Panel Menu Structure (Sheet 2 of 2)
Menu Option Submenu Description
