D.10
SEL-734B Capacitor Bank Control Field Reference Guide Date Code 20170207
Cable Drawings
Control Cables for Full-Size Enclosures With Individual Sensor Connectors
SEL-C538
Cable SEL-C538 connects to three switches (6-pin female connector).
J1
Phase 1
Phase 2
Phase 3
J2
J3
J4
Jacket:
• SOOW Cable
• 6 Conductor, 16 AWG
• Temperature Range:
–40° to 90°C
Industry Approvals:
• UL Flexible Cord UL Subject 62
• CSA Flexible Cord C22.2-49
• MSHA Approved
• RoHS Compliant
• Military Standard
• 3106 Style
• Insert Arrangement 22-14S
• Solid Backshell
• Maximum Diameter: 1.468 inch
• Military Standard
• 3106 Style
• Insert Arrangement 18-12S
• Solid Backshell
• Maximum Diameter: 1.22 inch
Wire Color
Red
White
Green
Black
Orange
Blue
Red
White
Green
Black
Orange
Blue
Red
White
Green
Black
Orange
Blue
Wire Type
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
Connector Pin
J1-U
J1-E
J1-D
J1-C
J1-N
J1-M
J1-U
J1-H
J1-G
J1-F
J1-R
J1-P
J1-U
J1-L
J1-K
J1-J
J1-T
J1-S
Connector Pin
J2-A
J2-B
J2-C
J2-D
J2-E
J2-F
J3-A
J3-B
J3-C
J3-D
J3-E
J3-F
J4-A
J4-B
J4-C
J4-D
J4-E
J4-F
Common
Common
Close
Open
52b
52a
Common
Common
Close
Open
52b
52a
Common
Common
Close
Open
52b
52a
Function
Phase 1
Phase 2
Phase 3
