Accessories

IE 400 PRO

IE 400 PRO SMOKY BLACK - cat. no. 507483

►

IE 400 PRO CLEAR - cat. no. 507484

►

Technical data: see “IE 400 PRO earphones”

You can find more information about the earphones on their product

page at:

www.sennheiser.com/ie-400-pro
