118

IE 4 earphones

►

Frequency ranges 40 – 20,000 Hz

Max. sound pressure level (SPL) 118 dB SPL

Sound pressure 106 dB (1 kHz,1 mW)

Impedance 32 Ω

Nominal impedance 16 Ω

Cable length 1.4 m

Connector 3.5 mm stereo plug, gold-plated
