Installing the SR IEM G4
27
Connecting audio signals
You can connect Mono or Stereo signals via the two input sockets BAL AF
IN L(I) and BAL AF IN R(II).
To do so, the SR IEM G4 must be configured for Mono or Stereo operation
in the menu. See “Mode menu item”.
In Stereo mode, you can receive the two input signals either as a
mixed mono signal or as a stereo signal. To do so, you must select
Focus or Stereo mode on the EK IEM G4 receiver. See “Mode menu
item”.
Mono
▷ Connect the output of an external device (e.g. a mixing console or an-
other SR IEM G4) to the audio input socket BAL AF IN L(I) + MONO us-
ing a suitable cable.
In Mono mode, the corresponding EK IEM G4 receiver must be oper-
ated in Focus mode. See “Mode menu item”.
