Installing the EK IEM G4
22
Attaching the diversity receiver to your clothing
You can use the belt clip to attach the diversity receiver to your waistband
or on a guitar strap.
The belt clip is detachable so that you can also attach the diversity receiver
with the antenna pointing downwards. To do so, withdraw the belt clip
from its fixing points and attach it the other way round.
►
The belt clip is secured so that it cannot slide out of its fixing points acci-
dentally.
To detach the belt clip:
▷ Lift the belt clip as shown in the diagram.
►
▷ Press one side of the clip downward on the fixing hole and pull it out of
the housing.
▷ Do the same thing on the other side.
