115
SR IEM G4
RF characteristics
►
Modulation
Broadband FM stereo
(MPX pilot tone procedure)
Receiving frequency ranges A1: 470 – 516 MHz
A: 516 – 558 MHz
AS: 520 – 558 MHz
G: 566 – 608 MHz
GB: 606 – 648 MHz
B: 626 – 668 MHz
C: 734 – 776 MHz
D: 780 – 822 MHz
E: 823 – 865 MHz
Receiving frequencies Max 1680 receiving frequencies,
adjustable in 25 kHz steps
20 frequency banks, each with up
to 16 factory-preset channels,
no intermodulation
6 frequency banks with up to 16
programmable channels
Switching bandwidth up to 42 MHz
Nominal/peak deviation ±24 kHz / ±48 kHz
MPX pilot tone (frequency/devia-
tion)
19 kHz/±5 kHz
Frequency stability ±10 ppm
Antenna output BNC socket, 50 Ω
RF output power at 50 ? Switchable:
Low: typically 10 mW
Standard: typically 30 mW
High: typically 50 mW
