Servomex 1100A - Page 207

Parameter
Code No.
Equivalent
Entry
Defaults/
Start-Up
Value
Unit Customer
Entered
Value
Description Enterable Range
of Values
Recommended
Range
* Cannot be user set.
§ Is dependent upon codes 11 and 18.
‡ Parameter 11 plus Parameter 18 must not exceed 199.99.
40
41
42
43
Alarm Lo Lo
Alarm Lo
Alarm Hi
Alarm Hi Hi
-10.00
-10.00
150.00
150.00
% O
2
% O
2
% O
2
% O
2
Lo Lo oxygen alarm level
Lo oxygen alarm level
Hi oxygen alarm level
Hi Hi oxygen alarm level
-10.00 to 163.80
-10.00 to 163.80
0 to 163.80
0 to 163.80
-10.00 to 100.00
-10.00 to 100.00
0 to 150.00
0 to 150.00
44 4.00 Alarm display and reset. 0 for current alarms
4 for cancel alarms
0 or 4 0 or 4.00
45 4.00 Analogue output freeze during 0 - freeze
Auto Cal/Check and loop gain @ 8 4 - live
B
C 0 or 4
0 or 4.00
D
46 0.46 Start auto-calibration/auto-check 0 to initiate auto-cal
47 0.00 days Auto-calibration period 0 to 163.80 in 0.1
increments
0 to 163.80
48 0.00 * Auto-cal error status - dependent on code 46
49 90.00 secs Zero to span gas DV lag B 0 to 163.80 5 to 163.80
50 90.00 secs Zero to span 90% response time # 0 to 163.80 5 to 163.80
51 5.0 mins Span gas stabilisation time # Parameters for 0 to 15.00 1 to 10.0
52 90.00 secs Span to zero gas DV lag # setting the 0 to 163.80 5 to 163.80
53 90.00 secs Span to zero 90% response time C maximum time 0 to 163.80 5 to 163.80
54 5.0 mins Zero gas stabilisation time # that any event 0 to 15.00 1 to 10.0
55 90.00 secs Zero to sample gas DV lag # during the 0 to 163.80 5 to 163.80
56 90.00 secs Zero to sample 90% response time # auto-calibration 0 to 163.80 5 to 163.80
57 1.5 mins Sample gas stabilisation time D cycle will take 0 to 15.00 0.1 to 5.0
58 0.0 days * Time since last auto-calibration
61 4.00 * Range change alarm
62 0.00 * Data link between Control and Interface units failed
63 0.00 * Zero gas flow failure alarm during auto-calibration
64 0.00 * Span gas flow failure during auto-calibration
65 0.00 * Sample gas flow failure alarm
66 0.00 * Gas tolerance out of limits during auto-calibration
