Operation
References
Operation References
3
A
/
V
+
S
A
/
V
+
S
Bottom view
Right view
Tripod socket
STILL button
[pp. 38, 39, 61, 71]
Power Zoom Wide angle/Telephoto
control buttons [pp. 20, 60]/
VOLume control buttons [p. 22]
Cassette compartment
door release [p. 12]
RECord START/STOP
button [pp. 19, 71]
Shoulder strap loop*
[p. 13]
Card slot door release [p. 70]
Audio/Video+S-video
(A/V+S) terminal
[pp. 23, 65]
DV terminal [p. 66]
Cassette compartment door [p. 12]
Terminal cover [p. 23]
POWER MICrophone
jack [p. 67]
Hand strap [p. 13]
Card slot door
[p. 70]
*Located inside the hand strap.
