Operating Instructions Chapter 3
CLV 42x bar code scanner
Product description
8 009 981/O078/16-08-2004 © SICK AG · Division Auto Ident · Germany · All rights reserved 3-1
3 Product description
3.1 Design
3.1.1 Scope of delivery
In the packaging the CLV is supplied with the following:
• two polling reflectors for automatic reading pulse generation
• an information sheet (note on device) with terminal diagram and Quick Start instructions
• an additional set of Class 2 laser warning labels (self-adhesive) in German/US English
and French/US English
Depending on the number of devices ordered, one or more copies of the following:
• CD ROM (no. 2 029 112) with
– "CLV-Setup" program for Windows
TM
and the "CLV-Setup Help" online help system
(HTML files)
– "CLV-Connect" PC software (HTML files showing terminal diagrams)
– CLV 42x Operating Instructions in English and German as PDF edition as well as
additional publications (connections module, other SICK bar code scanners)
– freely available "Acrobat Reader" PC software for reading PDF files
Note The latest versions of all the current publications/programs on the CD ROM can also be
downloaded from
www.sick.com.
Depending on the number of copies ordered, the delivery includes (optional):
• CLV 42x Operating Instructions in English and/or German (printed edition)
Chapter 10.11 Accessories, Page 10-38 provides an overview of the available installation
accessories, connection modules, cables and plug-in connections and sensors for reading
pulse generation.
3.1.2 Variants
The CLV is available in the following variants:
Type Order no. Scan procedure
CLV 420-0010 1 022 031 Line scanner, standard range
CLV 420-1010 1 022 032 Raster scanner, standard range
CLV 420-2010 1 022 033
Line scanner with 105° angle attachment, standard range
CLV 420-3010 1 022 034 Raster scanner with 105° angle attachment, standard range
CLV 421-0010 1 022 547 Line scanner, long range
CLV 421-1010 1 022 616 Raster scanner, long range
CLV 421-2010 1 022 617 Line scanner with 105° angle attachment, long range
CLV 421-3010 1 022 618 Raster scanner with 105° angle attachment, long range
CLV 422-0010 1 022 548 Line scanner, high density
CLV 422-1010 1 022 619 Raster scanner, high density
CLV 422-2010 1 022 620 Line scanner with 105° angle attachment, high density
CLV 422-3010 1 022 621 Raster scanner with 105° angle attachment, high density
Table 3-1: Variants of the CLV 42x
