Chapter 10 Operating Instructions
CLV 42x bar code scanner
10-38 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 981/O078/16-08-2004
Appendix
10.11 Accessories
10.11.1 Installation accessories
10.11.2 Connection modules
10.11.3 Extensions for connection modules
Part No. Description Fig.
2 020 077 Small mounting bracket with installation accessories Fig. 10-14, Page 10-40
2 020 078 Large mounting bracket with installation accessories Fig. 10-15, Page 10-40
Table 10-8: Accessories: installation accessories
Part No. Type Description
1 023 885 CDB 420-001 Connection module for one CLV 42x, with 15-pin D-Sub HD device socket, terminal strips (signal
distributors) for wiring the data and functional interfaces, internal 9-pin D Sub “Aux“ plug, cable grips
(dia. 4.5 to 10 mm (0.18 to 0.39 in)), polycarbonate housing, enclosure rating max. IP 65, operating
temperature 0 to +40 °C (
32 to 104 °F), operating voltage 10 to 30 V DC.
1 025 362 CDM 420-0001 Connection module for one CLV 42x, with 15-pin D-Sub HD device socket, terminal strips (signal
distributors) for wiring the data and functional interfaces, internal 9-pin D Sub “Aux“ plug, cable grips
(dia. 4.5 to 10 mm (0.18 to 0.39 in)), polycarbonate housing, enclosure rating max. IP 65, operating
temperature –35
1)
to +40 °C (–31
1)
to 104 °F), operating voltage 10 to 30 V DC, power consump-
tion 0.5 W without CLV 42x.
1 025 364 CDM 420-0101 As CDM 420-0001, with additional two 9-pin D Sub sockets (“Host“ and “Aux“ connections) on
front panel.
1) Without any mounting or electrical installation work, otherwise –20 °C (–4 °F)
Table 10-9: Accessories: Connection modules
Part No. Type Description
1 023 850 CMC 400-101 Parameter memory (Connection Module Cloning) as plug-in module for the CDB 420 or CDM 420
Connection Module. Storage of parameter set for CLV 42x (from firmware version V 1.30). Rotary
code switches for activating the network mode of the CLV 42x. Operating temperature 0 to +40 °C
(
32 to 104 °F), operating voltage 10 to 30 V DC via CDB 420 or CDM 420, power consumption
0.5 W.
2 029 466 CDM 400 Display module (Connection Display Module), 4 x 20 digits (LCD) with keyboard in optional cover for
the
CDM 420 Connection Module. Representation of reading results, reading diagnosis data and
messages from the CLV 42x (from firmware version V 1.30). Connection to the CDM 420 via ribbon
cable. Operating temperature 0 to +40 °C (
32 to 104 °F), operating voltage 18 to 30 V DC via
CDM 420, power consumption 1 W.
Prerequisite: CMC 400-101 parameter memory for controlling the display.
2 029 468 CMP 400 Power Supply Module (Connection Module Power) as plug-in module for the CDM 420 Connection
Module. Power supply for CLV 42x from an AC power line. Input 100 to 250 V AC/50 to 60 Hz,
output 24 V DC, max. 10.8 W (short-circuit proof). Connection to the CDM 420 via ribbon cable.
Operating temperature 0 to +40 °C (32 to 104 °F).
1 026 241 CMF 400-1001 Field bus gateway (Connection Module Fieldbus) as plug-in module for the CDM 420 Connection
Module. For connecting one CLV 42x (from firmware version V 1.60) to
Profibus-DP (slave) via
RS 232 data interface. With 9-pin D Sub socket on front panel for bus connection (enclosure rating
IP 20) and 5-core terminal strip for connecting 2 digital inputs and 2 digital outputs. Connection to
the CDM 420 via connector, operating temperature 0 to +40 °C (
32 to 104 °F), operating
voltage
18 to 30 V DC via CDM 420, power consumption 2 W.
1 026 643 CMF 400-1101 As CMF 400-1001, with enclosure rating max. IP 65
Table 10-10: Accessories: Extensions for connection modules
