SICK IDM series User Instructions

Symbology Reading Control
User Instructions
IDM corded
18
© SICK AG · Germany · All rights reserved · Subject to change without notice 8015906/2013-07-02
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
CS QR Code */ Micro QR Code * A0
CS Data Matrix * A1
CS Aztec Code * A3
CS Australian Post B0
CS British Post B1
CS Intelligent Mail barcode B3
CS Japanese Post B4
CS KIX Post B5
CS Planet Code B6
Readable Symbology
Setting
CS Postnet B8
Above symbologies marked with * are enabled as default. When you select “Auto”, the scanner only reads
those symbologies marked with *. When you set the minimum and maximum length of each symbology,
please note the data length of the scanned bar code doesn’t include start/stop characters.
