User Instructions
Symbology ID Table (1D Codes)
IDM corded
8015906/2013-07-02 © SICK AG · Germany · All rights reserved · Subject to change without notice
77
3 Appendix
3.1 Symbology ID Table (1D Codes)
Each AIM Code Identifier contains the three-character string ]cm where:
] = Flag Character; c = Code Character; m = Modifier Character
SICK ID AIM ID
Code Family Primary Format
Hex Value Char. Code Char. Modified Char.
UPC-A 2 0
UPC-A with 2 supple. 32 1
UPC-A with 5 supple. 42
A
2
UPC-E 3 0
UPC-E with 2 supple. 33 1
UPC-E with 5 supple. 43
E
E
2
UPC
Example: A UPC-A bar code 012345678950 with 2 supplement 12 is transmitted as
]E0012345678950]E112
Code 128 01 B m
Code 128
GS1-128 31 C
C
1
Codabar Codabar/NW-7 06 D F m
Standard/Industrial 2 of 5 08 I S 0
Matrix 2 of 5 38 K X 0
Interleaved 2 of 5 48 J I m
China Postal Code 58 L X 0
Code 25
German Postal Code 68 M I M
IATA IATA 15 O R M
Code 16K Code 16K 19 Q K m
UCC Coupon Code Z
UCC Coupon
Example: An UPC-A 512345678900 + GS1-128 81010123451297 barcode is
transmitted as ]E0512345678900]C181010123451297
Example: An EAN-13 9923456789019 + GS1-128 81010123451297 barcode is
transmitted as ]E09923456789019]C181010123451297
EAN/JAN-8 05 4
EAN/JAN-8 with 2 supple. 35 1
EAN/JAN-8 with 5 supple. 45
N E
2
EAN/JAN-13 04 0
EAN/JAN-13 with 2 supple. 34 1
EAN/JAN-13 with 5 supple. 44
F E
2
EAN/ JAN
Example: An EAN/JAN-8 barcode 49123562 with 5 supplements 12345 is transmitted as
]E449123562]E212345
Code 39 Code 39 09 H G m
Code 11 Code 11 10 P H m
MSI/ Plessey MSI/ Plessey 11 R M m
UK/ Plessey UK/ Plessey 12 S P 0
Telepen Telepen 13 T B m
GS1 Databar GS1 Databar
Composite Code Composite Code
14 X e m
Code 39 07 G A m
Code 39 Trioptic 47 W X 0
Code 39
Code 32 37 G A 0
Code 49 Code 49 20 U T m
PDF417 PDF417/ Micro PDF417 17 V L m
Codablock Codablock F 18 Y O m
Korea Post Korea Post Code 21 a X 0
Remark: Above examples are given for the transmission of AIM ID.
