If the programming family must take “Multiple Scan Selection”, “Cycling Scan Selection”, or “Dual Level
Selection” procedures, the family of the programming menu will be marked with the matched representing
symbol of Programming Category (P.C.) listed in the following table.
Conventions
Descriptions
Factory default value
Programming category
SS: Single scan selection
MS: Multiple scan selection
CS: Cycling scan selection
P.C.
DS: Dual level scan selection
( )
Necessary option code
[ ]
Selectable option code
2.2.1 Program & End
Please note that the IDM
Scanner will take 3-4 seconds to store parameters in internal Flash Memory
ASIC or non-volatile memory after you scan the “END”. Please don’t turn off the power before the
completion beeping. It may destroy all configured parameters.
The scanner will enter programming
mode and inhibit all non-
programming functions.
Scan
PROGRAM“
The scanner will exit programming
mode, and store all parameters in
Flash Memory ASIC or non-volatile
memory, then issue the completion
beeping.
Scan
END“
