2.10.2 Dollar Sign, Redundancy, 1D Code Inverse Reading
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Dollar Sign Control
SS Dollar sign output as “$“  0
SS
Dollar sign output as “￥“
1
SS Dollar sign output as “€“ 2
SS Dollar sign output as “£“ 3
SS Dollar sign output as “¢“ 4
SS None 0
SS Level 1  1
SS Level 2 2
SS Level 3 3
SS Level 4 4
SS Level 5 5
Redundancy
The Redundancy is the number of times the same barcode
has to be decoded before it is transmitted.
(To prevent potential misreading.)
SS Disable  0
1D Barcode Inverse
Reading
SS Enable  1
