Operation Control (IDM1xx series)
User Instructions
IDM corded
56
© SICK AG · Germany · All rights reserved · Subject to change without notice 8015906/2013-07-02
2.8.2 Presentation Control, Scan Rate, Flash Duty
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
SS Presentation mode 0
SS Flash mode 1
Presentation Control
SS Force mode 2
Scan Rate Control
SS Dynamic 0
SS Fixed 1
SS 1/2 duty cycle 0
SS 2/3 duty cycle 1
SS 3/4 duty cycle 2
Flash Duty Cycle
SS 4/5 duty cycle 3
Presentation Control
When the scanner is placed on the Hands-free stand, the scanner will be switched from hand-held scanning to
hands-free scanning automatically. Three hands-free scanning modes are available. You are recommended to
use flash mode or force mode while under insufficient ambient light.
Scan Rate Control
The scanner will have better motion tolerance when you select “Fixed” scan rate. It’s suitable for applications
which need higher motion tolerance on the move. But this may impact to the reading distance.
Flash Duty Cycle
The Flash Duty Cycle is designed to control the flashing frequency of the light source.
To Next Page
