Symbology Reading Control
User Instructions
IDM corded
36
© SICK AG · Germany · All rights reserved · Subject to change without notice 8015906/2013-07-02
2.4.18 GS1 DataBar Settings
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
GS1 DataBar Settings
SS Disable GS1 DataBar (RSS-14) 0
SS Enable GS1 DataBar (RSS-14) 1
SS Disable GS1 DataBar Limited 2
SS Enable GS1 DataBar Limited 3
SS Disable GS1 DataBar Expanded 4
SS Enable GS1 DataBar Expanded 5
SS Default (04) FIN
MS 01-Maximum (2 digits)
GS1 DataBar Min. Length
Only available for Expanded GS1 DataBar.
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
SS Default (74) FIN
MS 74-Minimum (2 digits)
GS1 DataBar Max.
Length
Only available for Expanded GS1 DataBar.
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
To Next Page
