2.4.17 Telepen Settings
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Telepen Settings
SS Disable Telepen  0
SS Enable Telepen 1
SS Select Telepen Numeric mode  2
SS Select Telepen Full ASCII mode 3
SS Disable check digit transmission  4
SS Enable check digit transmission 5
SS Default (04)  FIN
MS 01-Maximum (2 digits)
Telepen Min. Length
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
SS Default (98)  FIN
MS 98-Minimum (2 digits)
Telepen Max. Length
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
