2.4.23 Aztec Code Settings
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Aztec Code Settings
SS Disable Aztec Code 0
SS Enable Aztec Code  1
SS Default (01)  FIN
MS 01-Maximum (4 digits)
Aztec Code Min. Length
Scan 4 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
SS Default (3832)  FIN
MS 3832-Minimum (4 digits)
Aztec Code Max. Length
Scan 4 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
