User Instructions
Operation Control (IDM1xx series)
IDM corded
8015906/2013-07-02 © SICK AG · Germany · All rights reserved · Subject to change without notice
57
2.8.3 1D Barcode Reading Direction
PROGRAM F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
SS None 0
SS “S” 1
1D Barcode Forward-
reading Indication
MS User defined character (1 character)
2 [00-7F]
SS None 0
SS “X” 1
1D Barcode Backward-
reading Indication
MS User defined character (1 character)
2 [00-7F]
SS Disable 0
SS Enable prefix direction mark transmission 1
SS Enable suffix direction mark transmission 2
1D Barcode Direction
Indication Transmission
SS Enable both prefix and suffix direction mark
transmission
3
To Next Page
