2.11.6 Select a Barcode Symbology
You can select one or all types of barcode symbologies to use Condensed DataWizard for advanced
transmission arrangement. If you scan “00” to select all types, the Hand-held scanner will arrange all
incoming data to meet your pre-defined format. If you want to select only one type of barcode, please select
one of the option codes listed below.
1D Barcode Symbology
Code 128 01 Matrix 2 of 5 38
GS1-128 31 Interleaved 2 of 5 48
UPC-A 02 China Postal Code 58
UPC-A with 2 supplement 32 German Postal Code 68
UPC-A with 5 supplement 42 Standard/ Industrial 2 of 5 08
UPC-E 03 Code 93 09
UPC-E with 2 supplement 33 Code 11 10
UPC-E with 5 supplement 43 MSI/ Plessey 11
EAN-13 04 UK/ Plessey 12
EAN-13 with 2 supplement 34 Telepen 13
EAN-13 with 5 supplement 44 GS1 Data Bar 14
EAN-8 05 Composite Codes 14
EAN-8 with 2 supplement 35 IATA 15
EAN-8 with 5 supplement 45 Coupon Code 16
Codabar/ NW-7 06 PDF417/ Micro PDF417 17
Code 39 07 Codablock F 18
Code 32 37 Code 16K 19
Trioptic Code 39 47 Code 49 20
2D Barcode Symbology
QR Code A0 Data Matrix A2
Micro QR Code A0 Aztec Code A3
Postal Codes
Korea Post Code 21 Japanese Post B4
Australian Post B0 KIX Post B5
British Post B1 Planet Post B6
Intelligent Mail barcode B3 Postnet B8
