SICK OLM100 User Manual

FX3-CPU2 with Flexi Soft export file “SSI master” ID no. 9288609
T
able 20: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 24+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 24+1 bit
Checksum 0x05D4F6D0
FX3-CPU2 with Flexi Soft export file “SSI listener” ID no. 9290537
T
able 21: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 24+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 24+1 bit
Checksum 0xABCCACFD
FX3-CPU3 with Flexi Soft export file “SSI master” ID no. 9288609
T
able 22: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 24+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 24+1 bit
Checksum 0x081D56C6
FX3-CPU3 with Flexi Soft export file “SSI listener” ID no. 9290537
T
able 23: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 24+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 24+1 bit
Checksum 0xA6050CEB
7.3.1.2 Project and export file for SSI protocol 31+1 bit
FX3-CPU0 with Flexi Soft project file ID no. 9290043
T
able 24: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 Not assigned
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0xDEF61431
Table 25: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0x06D9C02F
Table 26: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0xA8C19A02
FX3-CPU1 with Flexi Soft export file “SSI master” ID no. 9290044
T
able 27: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0x40B50E17
7 CONFIGURATION
34
O P E R A T I N G I N S T R U C T I O N S | Safe Linear Positioning 8020941/12O9/2019-08-05 | SICK
Subject to change without notice
