SICK OLM100 User Manual

FX3-CPU1 with Flexi Soft export file “SSI listener” ID no. 9290539
T
able 28: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0xEEAD543A
FX3-CPU2 with Flexi Soft export file “SSI master” ID no. 9290044
T
able 29: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0x40B50E17
FX3-CPU2 with Flexi Soft export file “SSI listener” ID no. 9290539
T
able 30: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0xEEAD543A
FX3-CPU3 with Flexi Soft export file “SSI master” ID no. 9290044
T
able 31: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI master 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0x4D7CAE01
FX3-CPU3 with Flexi Soft export file “SSI listener” ID no. 9290539
T
able 32: Checksum with possible pin assignment on FX3-MOC1 module
MOC input E1 BG100.1 OLM sensor 1 as SSI listener 31+1 bit
MOC input E2 BG100.2 OLM sensor 2 as SSI master 31+1 bit
Checksum 0xE364F42C
7.3.1.3 Opening project file
1. Start Flexi Soft Designer.
2.
Click on Project.
3. Click on Open.
4. Select the project file.
5. Click on Open.
✓
The project file opens. The Hardware configuration view appears.
In the Configuration area, the entire hardware configuration of the Flexi Soft safety con‐
troller and the connected devices is displayed graphically.
7.3.2 Configuring the interface for BG100 motion sensor
The FX3-MOC1 Flexi Soft module provides the following inputs:
•
In
put ENC1 = OLM sensor 1
•
Input ENC2 = OLM sensor 2
CONFIGURATION 7
8020941/12O9/2019-08-05 | SICK O P E R A T I N G I N S T R U C T I O N S | Safe Linear Positioning
35
Subject to change without notice
