Interruption of connection to OLM sensor 1
T
able 100: Interruption of connection to OLM sensor 1
Check sequence Expected result Result OK?
1. Remove the plug connection from
OL
M sensor 1.
Switches to status:
XTIO output Q4 "KF130 stop request"
is deactivated.
Yes  No 
Interruption of connection to OLM sensor 2
T
able 101: Interruption of connection to OLM sensor 2
Check sequence Expected result Result OK?
1. Remove the plug connection from
OL
M sensor 2.
Switches to status:
XTIO output Q4 "KF130 stop request"
is deactivated.
Yes  No 
Interruption of connection to MOC1
Table 102: Interruption of connection to MOC1
Check sequence Expected result Result OK?
1. Remove the plug connection from
the MOC1 module.
Switches to status:
XTIO output Q4 "KF130 stop request"
is deactivated.
Yes  No 
Interruption of connection for the “Sensor ID 1” signal
T
able 103: Interruption of connection for the “Sensor ID 1” signal
Check sequence Expected result Result OK?
1. Remove the plug connection from
t
he Flexi Soft input.
Switches to status:
XTIO output Q4 "KF130 stop request"
is deactivated.
Yes  No 
Interruption of connection for the “Sensor ID 2” signal
T
able 104: Interruption of connection for the “Sensor ID 2” signal
Check sequence Expected result Result OK?
1. Remove the plug connection from
t
he Flexi Soft input.
Switches to status:
XTIO output Q4 "KF130 stop request"
is deactivated.
Yes  No 
17.1.10 Thorough check for foreseeable misuse and manipulation
Mounting
T
able 105: Bar code
Check sequence Expected result Result OK?
1. Check that the bar code tape has
been applied pr
operly, without
any tears or manipulation.
•
Onl
y the approved bar code tape
has been used.
•
The tape has been applied in line
with the requirements specified in
the OLM operating instructions.
•
There are no signs of the bar code
having been manipulated (e.g., for
test purposes).
•
The bar code tape is not contami‐
nated in any way.
Yes  N
o 
ANNEX 17
8020941/12O9/2019-08-05 | SICK O P E R A T I N G I N S T R U C T I O N S | Safe Linear Positioning
93
Subject to change without notice
