Check sequence Expected result Result OK?
1. Apply the test signal during back‐
w
ard movement.
2. Set test signal 1 “forward” to
active (XTIO input I1).
3. Set test signal 2 “backward” to
inactive (XTIO input I2).
The safety system switches to the safe
state (XTIO outputs Q1 "QA110.1
safety output (STO)" and Q2 "QA110.2
safety output (STO)" are deactivated).
Yes  No 
1. Apply the test signal during back‐
ward movement.
2. Set test signal 1 “forward” to
inactive (XTIO input I1).
3. Set test signal 2 “backward” to
inactive (XTIO input I2).
The safety system switches to the safe
state (XTIO outputs Q1 "QA110.1
safety output (STO)" and Q2 "QA110.2
safety output (STO)" are deactivated).
Yes  No 
17.1.8 Thorough check of the safety functions
External signal for requesting the safely limited speed (SLS) (if external signal used)
NOTE
Y
ou must undo the manipulation on the safety system again after each individual test
sequence. Then you must reset the safety system and carry out a restart.
Table 98: External signal for requesting the safely limited speed (SLS)
Check sequence Expected result Result OK?
1. Check that the external signal
sour
ce activates the SLS safety
function (outputs of the signal
source = 0 V).
A safe stop 2 (SS2) is initiated at a
speed > speed ID 2.
An automated restart is not performed.
Yes  No 
Emergency stop
T
able 99: Emergency stop
Check sequence Expected result Result OK?
1. Actuate the emergency stop
pushbut
ton.
The emergency stop pushbutton is eas‐
ily accessible.
When actuated, a safe stop 1 (SS1) is
initiated.
If an optional brake is in use, the brake
function will be activated once a stand‐
still has been reached.
Resetting the emergency stop device
does not trigger a restart.
All emergency stop pushbuttons within
the application have to be checked.
Yes  N
o 
17.1.9 Thorough check of faults on the transmission path
NOTE
Y
ou must undo the manipulation on the safety system again after each individual test
sequence. Then you must reset the safety system and carry out a restart.
17 ANNEX
92
O P E R A T I N G I N S T R U C T I O N S | Safe Linear Positioning 8020941/12O9/2019-08-05 | SICK
Subject to change without notice
