SICK OLM100 User Manual

13 Technical data
13.1 Data sheet
Table 67: Safe Linear Positioning data sheet
Safe Linear Positioning
SIL claim limit SILCL3 (EN 62061)
Category Category 4 (EN ISO 13849)
Performance level PL e (ISO 13849-1)
PFH
D
PFH
D
= 3.08 x 10
-8
MTTF
d
of t
he safety system High
T
M
(mis
sion time) 20 years (EN ISO 13849)
Response time of the system Max. 47.5 ms
Stopping distance extension 10 mm
1)
Resolution of the OLM100-1301/1401 mea‐
sur
ement system (part number: 1087575)
0.1 mm
Resolution of the OLM100-1501/1601 mea‐
surement system (part number: 1090629)
0.01 mm
Maximum measuring range with
OL
M100-1301/1401 (part number: 1087575)
1,677 m
Maximum measuring range with
OLM100-1501/1601 (part number: 1090629)
8,589 m
Maximum speed of the measurement system 4 m/s
Length of the SSI connection cable between
OL
M 2 and the FX3-MOC1 input (direct con‐
nection)
Max. 50 m
(transmission rate < 400 kBaud)
Length of the SSI connection cable between
OLM 1 and the external process controller
(parallel infeed to FX3-MOC1)
Max. 50 m
(transmission rate < 400 kBaud)
Length of the SSI connection cable between
the splitter (coupling point) and the FX3-MOC1
input
Max. 2 m
(transmission rate < 400 kBaud)
Supply voltage U
V
24 V DC (16.8 V DC ... 28.8 V DC) (SELV)
2)
Ambient operating temperature Flexi Soft: -20 … +55 °C
OL
M100 Hi: -30 … +55 °C
Storage temperature –25 … +70 °C
Air humidity 10…95%, non-condensing
Permissible operating height Max. 2,000 m above sea level (80 kPa)
Enclosure rating (EN 60529) Flexi Soft: IP54
OL
M100 Hi: IP65
Safe state The safety-related semiconductor outputs are
in t
he OFF state.
Electromagnetic compatibility EN 61000-6-2, EN 61000-6-4
Vibration resistance EN 60068-2-6, EN 60068-2-64
Shock resistance EN 60086-2-27
1)
The user must use the overall response time and other application-specific parameters to calculate the
s
topping distance. The user must then add another 10 mm on to the calculated stopping distance, which
apply owing to internal filters.
2)
The external supply voltage must jumper a brief power failure of 20 ms as specified in IEC 60204-1. Suit‐
able power supply units are available as accessories from SICK.
13 T
ECHNICAL DATA
78
O P E R A T I N G I N S T R U C T I O N S | Safe Linear Positioning 8020941/12O9/2019-08-05 | SICK
Subject to change without notice
