The additional information provided in this chapter just offers an overview of the soft‐

are.

7.3.1 Pre-configured project files

Pre-configured project files for the safety system are available under the following link:

www

.sick.com/Safe_Linear_Positioning

Separate project files are available for both variants of the sensor and they have differ‐

ent sensor se

ttings. In these project files, all configurable parameters are set to stan‐

dard values.

Aside from the project files provided, export files are available on the internet. These

correspond to the hardware configuration and logic of the project files, but can be

imported into any Flexi Soft CPU module (from firmware version 4.xx). The checksums

listed below result. After downloading or importing, it must be checked whether the

checksum of the project corresponds to the respective checksum indicated here. The

checksums change if modifications are made to the parameters or logic.

7.3.1.1 Project and export file for SSI protocol 24+1 bit (SAPPD3E-14AP003)

FX3-CPU0 with Flexi Soft project file ID no. 9288608

able 15: Checksum with possible pin assignment on FX3-MOC1 module

MOC input E1 Not assigned
