Chapter 10 Operating instructions
S100
44 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
10 Care and maintenance
Do not make any repairs to the device!
The S100 does not contain any repairable components. For this reason do not open the
S100 components and only replace the parts that are described in the following chapters
as replaceable.
Switch the entire machine/system off line!
The system could inadvertently start up while you are replacing the optics cover. As a
matter of principle, always isolate the machine from the power supply during all work on
the machine and laser scanner.
10.1 Cleaning optics cover
The S100 laser scanner is largely maintenance-free. The optics cover on the laser scanner
should however be cleaned regularly and if it is contaminated.
Do not use aggressive cleaning agents.
Do not use abrasive cleaning agents.
Static charges cause dust particles to be attracted to the optics cover. You can diminish
this effect by using the anti-static plastic cleaner (SICK Part No. 5600006) and the SICK
lens cloth (Part No. 4003353) (see section 13.3 “Accessories/spare parts” on page 63).
How to clean the optics cover:
Use a clean and soft brush to remove dust from the optics cover.
Now wipe the window for light output on the optics cover with a clean and damp cloth.
10.2 Replacing optics cover
Perform an optics cover calibration with the aid of the CDS-S100 after the replacement
of the optics cover!
The level of contamination is measured continuously during the operation of the S100. For
this purpose the optics cover calibration must first be performed; this then serves as a
reference for the contamination measurement (status = not contaminated).
The optics cover calibration is only allowed to be performed with a new optics cover! The
new optics cover must be free of contamination at the time of the optics cover calibration.
The optics cover calibration should be performed at room temperature (10-30 °C)!
If the optics cover is scratched or damaged, you must replace the optics cover. Order the
replacement optics cover from SICK (see section 13.3 “Accessories/spare parts” on
page 63).
The optics cover on the S100 is an optical part that must not be soiled or scratched on
replacement.
The optics cover is only allowed to be replaced by authorised personnel in a dust and
dirt-free environment.
Never replace the optics cover during ongoing operation, as internal parts may be
irreparably damaged in certain circumstances and dust particles may enter the device.
It is imperative that you avoid contamination of the inside, e.g. with fingerprints.
