Chapter 12 Operating instructions
S100
52 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Technical specifications
12 Technical specifications
12.1 Characteristics
Remission Material
Approx. 2% Black shoe leather
Approx. 5% Mat black paint
Approx. 20% Grey cardboard
Approx. 80% Writing paper
Approx. 100% White plaster
>300% Reflective films
>2000% Reflectors
Fig. 30: Diagram of the object
diameter necessary for
switch off and the necessary
remission
Tab. 22: Examples for levels
of remission of various
materials
Remission [%]
1
10
100
10
50
500
30
3
Object diameter [mm]
Scanning range [m]
Object diameter
Object remission
50
5
300
30
10
1
0
5
1.8
5
8
Object diameter determined in the near range by approaching
