SICK S100 Standard User Manual

Chapter 12 Operating instructions
S100
60 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Technical specifications
12.4 Dimensional drawings
12.4.1 S100
12.4.2 Mounting kits
Fig. 31: Dimensional drawing
S100 (mm)
Fig. 32: Dimensional drawing,
mounting kit 1a (mm)
DIN 74F5
16
21.9
15.9
110.2
74.7
49
15.7
4
73
24
79.3
25
M5
 ×  7.5
10.5
54.5
106
5
∅ 94
102
36.5
73
79.3
116
152
M5

×

7.5
49
±0.2
Part number 2034324
