Operating instructions Chapter 6
S100
8012238/YY30/2015-02-20 © SICK AG • Subject to change without notice 35
Electrical installation
6.2.2 Wire cross-sections
Use the following wire cross-sections for the individual connections:
Cable
Recommended wire cross-
sections
Screened
System cables for supply
voltage, outputs, static
inputs
9-15 cores,
0.5-1 mm²
No
2)
CANopen 3 × 0.22 mm² Yes
If you do not want to assemble the system plug yourself, you will find suitable cables in the
ordering information (see section 13.3.4 “Self assembly connecting cables” on page 64).
6.3 Pre-assembled system plugs
To connect the S100 variants, the following pre-assembled system plugs are available (see
also section 13.3.2 “System plug S100” on page 64):
For S100 Standard: SX0B-B1105G, SX0B-B1110G and SX0B-B1120G
With 11 cores, unscreened (cable gland M16), 5, 10 or 20 m long
For S100 Professional: with static inputs SX0B-B1505G and SX0B-B1510G
With 15 cores, unscreened (cable gland M16), 5 or 10 m long
Pin Signal Wire colour SX0B-B1105G SX0B-B1110G SX0B-B1120G SX0B-B1505G SX0B-B1510G
FE Green  
1 +24 V DC Brown  
2 0 V DC Blue  
3 Switching output
1
Grey  
4 Switching output
2
Pink  
5 IN A Red 
6 IN B Yellow 
7 IN C White/Blue 
8 IN D White/Grey 
9 – White/Violet 
10 – White 
13 ERR White/Black  
14 1 White/Brown  
15 2 Red/Blue  
16 STBY White/Green  
2)
Screening is recommended if there is a significant EMC interference in the area.
Tab. 8: Recommended wire
cross-sections
Recommendation
Tab. 9: Pin assignment pre-
assembled system plug
