Operating instructions Chapter 12
S100
8012238/YY30/2015-02-20 © SICK AG • Subject to change without notice 53
12.2 Response times
The total response time of your application is dependent on …
the basic response time of the S100.
the multiple sampling set.
How to calculate the total response time T
S
:
T
S
= t
B
+ T
MFA
Where …
t
B
= Basic response time = 40 ms
T
MFA
= Supplement due to multiple sampling > 1
Multiple sampling
Double multiple sampling is set on the S100 from the factory. For a multiple sampling of
2 or higher you must add a supplement of 40 ms to the basic response time.
Multiple sampling Supplement Basic response time + supplement
1 time 0 ms 40 ms
2 times (default) 40 ms 80 ms
3 times 80 ms 120 ms
4 times 120 ms 160 ms
5 times 160 ms 200 ms
6 times 200 ms 240 ms
7 times 240 ms 280 ms
8 times 280 ms 320 ms
9 times 320 ms 360 ms
10 times 360 ms 400 ms
11 times 400 ms 440 ms
12 times 440 ms 480 ms
13 times 480 ms 520 ms
14 times 520 ms 560 ms
15 times 560 ms 600 ms
16 times 600 ms 640 ms
Tab. 23: Supplements for
multiple sampling
