SICK S100 Standard User Manual

Operating instructions Chapter 9
S100
8012238/YY30/2015-02-20 © SICK AG • Subject to change without notice 43
Commissioning
9.2 Re-commissioning
If the S100 has already been placed in operation once, however the device has been
temporarily replaced in the meantime, the S100 reads the configuration saved from the
system connector remaining on the machine or system.
The following indications are possible:
Step Display Meaning
1 , , ,,
, , , 
Power-up cycle, testing the 7segment display. All
segments are activated sequentially.
2  Waiting for device on the CAN bus
3 
 or 
  
Waiting for valid local inputs
or
Waiting for valid virtual inputs via CANopen.  is
indicated in the CAN state Preoperational,  in the
CAN state Operational.
(Only possible with S100 Professional.)
or
Device in the CAN Preoperational state
4 No display
or

Device ready for operation
or
Device ready for operation but object in the
switching field
Other display Interlock activated. Malfunction (see section 11.2
“Error and status indications on the LEDs” on
page 46).
Display Meaning







  
Power-up cycle, step 1
    
Power-up cycle, step 2
   

The device is ready, no object in one of the
switching fields.
   

Or: The device is ready, object in the switching field
that is allocated to switching output Q1.
   

Or: The device is ready, object in the switching field
that is allocated to switching output Q2.
Other display Interlock activated. Malfunction (see section 11.2
“Error and status indications on the LEDs” on
page 46).
Tab. 17: 7segment display
during and after the power
up sequence on re-
commissioning
Tab. 18: LED indication after
the power up sequence
