Chapter 13 Operating instructions
S100
64 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Ordering information
13.3.2 System plug S100
System plug Features Description Part number
SX0B-A0000G One cable gland M16
and one blanking
plug M12, on the
rear
Without cable 2032807
SX0B-B1105G Pre-assembled, 5 m long cable,
11 cores
2032859
SX0B-B1110G Pre-assembled, 10 m long
cable, 11 cores
2032860
SX0B-B1120G Pre-assembled, 20 m long
cable, 11 cores
2032861
SX0B-B1505G One cable gland M16
and one blanking
plug M12, on the
rear
Pre-assembled, 5 m long cable,
15 cores
2034264
SX0B-B1510G Pre-assembled, 10 m long
cable, 15 cores
2034265
13.3.3 Service cable
Part Part number
Service cable approx. 2 m: For connecting the configuration connection
to the serial interface on the PC, M8×4-pin/DSub 9-pin (DIN 41642)
6021195
Service cable approx. 10 m: For connecting the configuration
connection to the serial interface on the PC, M8×4-pin/DSub 9-pin
(DIN 41642)
2027649
USB service cable approx. 2 m: For connecting the configuration
connection to the USB interface on the PC M8×4-pin/USB-A plug
6034574
USB service cable approx.10 m: For connecting the configuration
connection to the USB interface on the PC M8×4-pin/USB-A plug
6034575
USB/RS-232 adapter: USB-A plug to D-Sub socket, 9-pin 6035396
13.3.4 Self assembly connecting cables
Part Part number
15-pin, Wire cross-section 0.56 mm² (AWG 20), on 100 m reel 6030795
CANopen cable, By the meter (2 × 2 × 0.22 mm
2
) 6035263
M16 EMC-proof cable gland for CANopen connections,
permissible cable diameter 3-6.5 mm
5318530
Adapter for cable entry from M12 to M16 5320690
M12 EMC-proof cable gland for EFI connections, permissible
cable diameter 3-6.5 mm, height 19 mm
5308757
M12 EMC-proof cable gland for EFI connections, permissible
cable diameter 3-6.5 mm, height 25 mm
5314772
13.3.5 Documentation
Part Part number
CDS-S100 (Configuration & Diagnostic Software — S100) on CD-ROM
including online documentation and operating instructions in all
available languages
2042818
Tab. 27: Part numbers
system plugs S100
Tab. 28: Part numbers
service cables
Tab. 29: Part numbers self
assembly connecting cables
Tab. 30: Part numbers
documentation
