Chapter 12 Operating instructions
S100
54 © SICK AG • Subject to change without notice 8012238/YY30/2015-02-20
Technical specifications
12.3 Data sheet
Minimum Typical Maximum
General data
Laser protection class as per
IEC 608251:2001
Laser class 1 (complies with
21 CFR 1040.10 and 1040.11)
Enclosure rating according to EN 60529 IP 65
Protection class according to
EN 50178:199710
II
Ambient operating temperature –10 °C +50 °C
Storage temperature –25 °C +70 °C
(≤ 24 h)
Humidity non-condensing (taking into account
the operating temperature range)
95%
Vibration as per IEC 60068-2-6
Frequency range 10 Hz 150 Hz
Amplitude 0.35 mm or 5 g
Shock resistance according to
IEC 60068229
Single shock 15 g, 11 ms
Continuous shock 10 g, 16 ms
Sender Pulsed laser diode
Wavelength 895 nm 905 nm 915 nm
Divergence of the collimated beam (solid
angle)
14 mrad
Pulse duration 4.5 ns
Average output power 1.76 mW
Light spot size at optics cover 8 mm
Size of light spot at 2.0 m scanning range 28 mm
Size of light spot at 10.0 m scanning range 140 mm
Housing
Material Aluminium die-cast
Colour RAL 9005 (black)
Optics cover
Material Polycarbonate
Surface finish Outside with scratch-resistant coating
System plug ESD protected
Material Aluminium die-cast
Colour RAL 9005 (black)
Tab. 24: Data sheet S100
