Inputs / outputs 9410 series
4. Configure the digital output by selecting the parameter and clicking Edit.
Parameter Value/range Description
Source Digital/Boolean Link this input to the value that drives the state
of the digital output.
If Source is not linked, the digital output state is
driven by the Force ON, Force OFF values.
Force ON Pulse Link this input to a pulse that forces the digital
output on for the PulseWidth duration,
regardless of the Source input.
Force OFF
1
Pulse Link this input to a pulse that forces the digital
output off.
Normal
1
Pulse Pulsing this input will switch the driver of the
digital output from Force ON to Source.
Polarity Inverting/non-inverting Specifies if the signal to the digital port is
inverted or not inverted.
PulseWidth 0 - 2,000,000 Specifies the duration of the pulse, in seconds.
Setting this parameter to 0 sets the digital output
continuously on.
Port
—
The physical digital output port connection. Only
available ports are shown.
1
These parameters are only valid when pulse width is set to 0.
Configuring option module digital outputs using ION Setup
You can configure option module digital outputs using ION Setup.
One form A digital output is available on the base of the meter. You can add more
digital outputs using optional I/O modules.
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
3. Navigate to Expansion Module > Option I/O Modules and select the module tab
that corresponds to the option module with the digital output you want to
configure.
4. Select the digital output channel and click Edit. The setup screen for that digital
output is displayed.
7EN05-0336-03 147
