9410 series Communications
this is an advanced procedure that requires in-depth knowledge of your meter, its
underlying architecture, and the system in which it is installed.
WARNING
UNINTENDED OPERATION
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
Do not use this device for critical control or protection applications where human or
equipment safety relies on the operation of the control circuit.
1. Start ION Setup.
2. Connect to your meter in advanced mode.
3. Navigate to the GGIO Onboard folder and double-click on the module in the
righthand pane.
4. Select the Setup Registers tab.
5. Select the SPCS Control Mode register that corresponds to the digital output you
want to control through IEC 61850 and click Edit. A dialog appears.
6. Select IEC 61850 CTLVAL from the dropdown list and click OK.
7. Select the Inputs tab.
8. Select the digital output Status register for the digital output that you want to
control through IEC 61850. Click Delete.
NOTE: This digital input register must be deleted in order to prevent a circular
reference that will cause the affected modules to go offline.
9. Click Send to send your changes to the meter.
10. Select the Setup Registers tab and confirm that the Digital Output module’s
setup registers are appropriately configured.
11. Select the Inputs tab.
12. Select the Source register and click Edit.
13. Navigate to the IEC 61850 GGIO Onboard folder and select the SPCS.stVal
output register that corresponds to the digital output.
14. Click OK and Send to save your changes to the meter.
See the ION Reference, available from www.usa.siemens.com/pds, for
information about the IEC 61850 GGIO and Digital output modules.
DNP
Your meter can be integrated into a DNP network as a DNP slave.
The Distributed Network Protocol Version 3.0 (DNP 3.0) is an open protocol used in
the electric utility industry for communications and interoperability among substation
computers, Remote Terminal Units (RTUs), Intelligent Electronic Devices (IEDs, e.g.
meters), and master stations.
DNP supported features and default implementation
Your meter is pre-configured for basic DNP Slave functionality.
92 7EN05-0336-03
