9410 series Specifications overview
DC control power
Operating range 110 to 415 V DC ± 15%
Burden (meter only) max. 6 W at 300 V DC
Burden (fully optioned meter) 17 W at 300 V DC
Ride-through time 100 ms (6 cycles at 60 Hz) min., any condition
Low-voltage DC control power
DC control power
Operating range 20 to 60 V DC +/-10%
Burden (fully optioned meter) max. 17 W at 18 to 60 V DC
Digital output
Number 1
Type Form A solid-state
Maximum load voltage 30 V AC / 60 V DC
Maximum load current 75 mA
ON resistance 13 – 40 Ω at 25 °C (77 °F)
Signal type Continuous or pulse
Pulse frequency ≤ 25 Hz
Digital inputs
Number 3
Type Externally excited, polarity independent
Event timestamp accuracy ± 1 ms
Maximum voltage 30 V AC / 60 V DC
Pulse frequency ≤ 25 Hz
Response time 20 ms
Minimum pulse width 20 ms
Current draw ON: ≤ 2.5 mA
OFF: ≤ 0.5 mA
ON state 4 to 30 V AC / 4 to 60 V DC
OFF state 0 to 1.4 V AC / 0 to 2.0 V DC
IRIG-B IRIG-B00x format (unmodulated IRIG-B time code)
Coded expressions 0 to 7 are supported but the year data is not used.
Environmental characteristics
Operating temperature -25 ºC to Max temp (-13 ºF to Max temp)
Maximum operation temperature is based on the quantity and type of attached option modules. See
Maximum operating temperature, page 197.
Storage temperature -40 to 85 °C (-40 to 185 °F)
Humidity rating 5 – 95% RH non-condensing
Maximum dewpoint: 37 °C (99 °F)
