9410 series Alarms and alerts
Alarm Alarm icon Alarm icon flash Alarm LED Meter display
Historic low Blue outline bell Flash if not acknowledged • Flash if not
acknowledged
• Steady if
acknowledged
No flash
No active or
unacknowledged alarms
Gray solid bell No flash Off No flash
If there are multiple active alarms, the meter displays the alarm condition associated
with the most important active alarm. If there are multiple unacknowledged historic
alarms, the meter displays the alarm condition associated with the most important
unacknowledged historic alarm.
NOTE: To stop an alarm from being displayed without impacting other metering
features, set the alarm priority to Info Only.
Default alarms
Your meter comes with default alarms.
NOTE: Some alarms require configuration in order to operate.
Name Priority Description
Current Sag Ph1 - 3 High Current sag alarms for phase 1, 2, 3
Current Swell Ph1 - 3 High Current swell alarms for phase 1, 2, 3
Sag/Swell High Voltage sag/swell alarm
Over I unbal Medium Over unbalanced current alarm
Over V unbal Medium Over unbalanced voltage alarm
Over THD V1 - 3 Medium Over total harmonic distortion (THD) voltage alarms
Over kW (P) sd Medium Over kW sliding demand alarm
Over I a - c, (1 -3) 4 Medium Over current alarms
V1 - V3 Setpoint Medium Voltage setpoint alarms
Freq Setpoint Medium Frequency setpoint alarm
4-30 Volt Intrp Ph1 - 3 Low 4-30 voltage interruption power quality alarms
Digital In Info Only Digital input alarms
Number of alarms determined by the total number of available digital inputs
NOTE: These alarms are not displayed by default.
Alarm information
You can view information about an alarm from your meter’s display.
Only alarms with a priority of low, medium or high are displayed.
Parameter Description
Alarm The name of the alarm (for example, Over THD V1).
Priority Low, medium or high alarm priority.
Date The date and time the alarm was triggered.
Duration The duration of the alarm (only applies to inactive alarms).
154 7EN05-0336-03
