Specifications overview 9410 series
System types (for MID-compliant
applications)
• 3-phase 4-wire Wye grounded
• 3-phase 3-wire Delta ungrounded
Current rating 0.05 – 5(10)A
Nominal frequency 50 Hz
Energy pulsing LED Pulse weight – 5000 imp/kWh
To comply with MID, the meter must be installed in MID certified cabinets rated for IP51 or better.
Remote display
See your remote meter display’s installation sheet for additional remote meter display
specifications.
IP degree of protection Front: IP54
Rear: IP30
Cable CAT5/5e/6/6a
Mounting position Vertical
Display type 1/4 VGA color graphic TFT LCD 320 x 240 resolution
Display backlight White LED
Viewable area 70.6 x 52.9 mm (2.78 x 2.08 in)
Keypad 5 button
Option modules
See your option module’s installation sheet for additional option module specifications.
US2:948M2AO4AI Analog (2 out, 4 in)
Maximum number of modules 4
Input resistance < 300 Ω (current mode)
> 500 kΩ (voltage mode)
Max analog input current/voltage 20 mA / 30 V DC
Maximum meter operating temperature 25 ºC to Max temp (-13 ºF to Max temp)
Maximum operation temperature is based on the quantity and type of
attached option modules. See Maximum operating temperature, page
197.
US2:948M2DO6DI Digital (2 out, 4 in)
Maximum number of modules 4
Maximum meter operating temperature -25 ºC to Max temp (-13 ºF to Max temp)
Maximum operation temperature is based on the quantity and type of
attached option modules. See Maximum operating temperature, page
197.
Other
Meter start time Typical: 18 seconds (power up to measurement)
Meter memory 500 MB
7EN05-0336-03 199
