Basic setup 9410 series
Voltage polarity setup
Parameter Values Description
Va Polarity Normal, Inverted The polarity of the potential transformer on Va
Vb Polarity Normal, Inverted The polarity of the potential transformer on Vb
Vc Polarity Normal, Inverted The polarity of the potential transformer on Vc
Current polarity setup
Parameter Values Description
Ia Polarity Normal, Inverted The polarity of the current transformer on Ia
Ib Polarity Normal, Inverted The polarity of the current transformer on Ib
Ic Polarity Normal, Inverted The polarity of the current transformer on Ic
I4 Polarity Normal, Inverted The polarity of the current transformer on I4
Nominal values
Parameter Values Description
V Nominal 1 to 999,999 The nominal (normal) voltage of the power system
I Nominal 1 to 999,999 The nominal (normal) current of the power system
Nominal
Frequency
50, 60 The nominal (normal) frequency of the power
system
Minimum configuration requirements for basic metering
At a minimum, you must configure some parameters to help your meter perform basic
metering functions.
Setup screen Screen Minimum configuration
Meter Setup Volts Mode Volts mode
PT/CT Setup PT, CT and I4 CT primary and secondary
Nominal values V nominal, I nominal, Nominal frequency
NOTE: You must also configure all the parameters related to the meter features
you are using, for example, you must configure the DNS server address if you are
using the meter’s DNS feature.
7EN05-0336-03 19
