9410 series Specifications overview
Safety
Safety construction IEC/EN 61010-1 ed.3, CAT III, 400 VLN / 690 V LL
UL 61010-1 ed.3 and CSA-C22.2 No. 61010-1 ed.3, CATIII, 347 V LN /
600 V LL
IEC/EN 62052-11, Protective Class II
Ethernet communications
Number of ports 2 (the second connector functions as an Ethernet switch for networking devices)
Maximum cable length 100 m (328 ft), per TIA/EIA 568-5-A
Cable type CAT5/5e/6/6a
Connector type Unshielded RJ45 modular connector (2)
Mode 10Base-T, 100Base-TX, Auto-MDIX
Data rate up to 100 Mbps
FTP Maximum simultaneous transfer connections (sessions): 2
Default timeout period: 90 seconds
IEC61850 maximum simultaneous client
connections
4
RS-485 communications
Number of ports 1
Maximum cable length 1200 m (4000 ft)
Maximum number of devices (unit loads) Up to 32 devices on the same bus
Parity None, even, odd
Baud rate 2400 – 115200, 19200 recommended
Real-time clock
Clock drift (time error) 20 ppm max at 25 °C (77 °F)
Battery backup time Minimum 7 years under specified storage conditions
MID
Applicable MID standards and class
index
• EN 50470-1:2006 Class C
• EN 50470-3:2006 Class C
Type of measuring equipment Static watt-hour meter
Mechanical environment M1
Electromagnetic environment E2
Cover sealing type Wire and crimp
Applicable measurements Active import/export energy metering
198 7EN05-0336-03
