9410 series Specifications overview
Specifications overview
This section provides additional specifications for your meter and accessories.
The information contained in this section is subject to change without notice. You can
download updated documentation from www.usa.siemens.com/pds or contact your
local Siemens Industry Industry representative for the latest updates.
See your device’s installation sheet for specifications related to installation, such as
measured current and voltage ranges, inputs/outputs and control power information.
Mechanical characteristics
9410DC panel mount meter
Mounting position Vertical
IP degree of protection Display: IP54
Meter body: IP30 (except connectors)
Display type 1/4 VGA color graphic TFT LCD, 320 x 240 resolution
Display backlight White LED
Viewable area 70.6 x 52.9 mm (2.78 x 2.08 in)
Keypad 5 button
Maximum number of option modules 4 (based on mechanical stress and required IP rating)
9410TC DIN meter
Mounting position Horizontal TS35 DIN rail
IP degree of protection Meter body: IP30 (except connectors)
Maximum number of option modules 4 (based on mechanical stress and required IP rating)
Mechanical compliance
Vibration IEC 60068-2-6
Shock IEC 60068-2-27
Electrical characteristics
True RMS 4–quadrant metering up to the 63rd harmonic on three-phase systems, 256
samples per cycle.
NOTE: Reactive energy and demand values are based on the fundamental, and
do not include higher harmonics. Other energy and demand values are measured
using the entire signal including harmonics. Contact Technical Support for more
information.
NOTE: Table below assumes default configuration. Some values can be changed
through framework and/or custom configuration.
194 7EN05-0336-03
