Specifications overview 9410 series
Measurement accuracy
IEC 62053-22 - active energy Class 0.2S
IEC 62053-24 - reactive energy Class 0.5S
IEC 61557-12 PMD/SD/K70/0.2 and PMD/SS/K70/0.2
Active power (P) IEC 61557-12 Class 0.2 (± 0.2%)
Reactive power (Q
V
) IEC 61557-12 Class 1 (± 1%)
Apparent power (S
V
) IEC 61557-12 Class 0.2 (± 0.2%)
Current (I) IEC 61557-12 Class 0.2 (± 0.2%)
Voltage (U) IEC 61557-12 Class 0.2 (± 0.2%)
Frequency (f) IEC 61557-12 Class 0.02 (± 0.02%)
Power quality
IEC 61000-4-30 edition 2 Class S
IEC 62586–2 edition 1
Voltage unbalance (U
nb
) IEC 61557-12 Class 0.2 (± 0.2%)
Voltage harmonics (U
h
) IEC 61557-12 Class 1 (± 1%)
Voltage THD (THD
u
) IEC 61557-12 Class 1 (± 1%)
Current harmonics (I
h
) IEC 61557-12 Class 1 (± 1%)
Current THD (THD
i
) IEC 61557-12 Class 1 (± 1%)
Waveform capture 16 - 256 cycles per sample
Voltage inputs
Specified accuracy range 57 to 400 V L-N / 100 to 690 V L-L (Wye) or 100 to 600 V L-L (Delta)
Specified accuracy frequency 42 to 69 Hz (50/60 Hz nominal)
Current inputs
Specified accuracy current range 50 mA – 10 A
Withstand 20 A continuous, 50 A @ 10 sec/hr, 500 A @ 1 sec/hr
Burden 0.01 VA max at 5 A
Impedance 0.3 mΩ (typical)
Standard control power
AC control power
Operating range 50/60 Hz ± 10%: 90 to 415 V AC L-N ± 10%
400 Hz: 90 to 120 V AC ± 10%
Burden (meter only) max: 7.2 W / 18 VA @ 415 V (45 – 65 Hz)
max: 4.5 W / 8 VA @ 120 V (400 Hz)
Burden (fully optioned meter) max: 18 W / 36 VA @ 415 V (45 – 60 Hz)
max. 18 W / 28 VA @ 120 V (400 Hz)
Ride-through time 100 ms (6 cycles at 60 Hz) min., any condition
200 ms (12 cycles at 60 Hz) typ., 120 V AC
500 ms (30 cycles at 60 Hz) typ., 415 V AC
