9410 series Inputs / outputs
10. Configure your meter to log the input metering data if required.
Parameter Description
Pulse Weight Enter the value per pulse.
Units Select the measurement units associated with the pulse.
NOTE: Include source identification information by entering “@” followed
by the source identifier.
Demand Period Enter the frequency in minutes that input metering data is calculated in your
energy management system.
Rate Select the rate associated with the defined Units.
Scaling Select the scaling value based on the relationship between Units and Rate.
Time Base Select the value and units to match the Rate.
Digital outputs
Digital output applications
Digital outputs are typically used in switching applications, for example, to provide on/
off control signals for switching capacitor banks, generators, and other external
devices and equipment.
The digital output can also be used in demand synchronization applications, where the
meter provides pulse signals to the input of another meter to control its demand period.
The digital output can also be used in energy pulsing applications, where a receiving
device determines energy usage by counting the kWh pulses coming from the meter’s
digital output port.
Related Topics
• Option modules
Configuring onboard digital outputs using ION Setup
You can use ION Setup to configure your meter’s digital outputs.
One form A digital output is available on the base of the meter. You can add more
digital outputs using optional I/O modules.
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
3. Navigate to either onboard or expansion I/O, Digital Outputs, and select a digital
output tab.
146 7EN05-0336-03
