9410 series Alarms and alerts
6. Click Setup.
The Alarm Learning Setup screen is displayed.
7. Configure the learning parameters for each setpoint and click Save.
8. Click Start All to begin setpoint learning for all setpoints.
– When setpoint learning is in progress, an asterisk is displayed next to the
setpoint.
– Click Abort to stop learning for a specific setpoint. To stop all setpoint learning,
repeat for each setpoint tab.
9. Apply the learned setpoint values:
– Automatic: the setpoint values are automatically applied unless the learning
process has issues or the learned values are invalid.
– Manual: navigate to Alarming > Setpoints and click Learn. On each setpoint
tab, click Install to apply the learned values to that setpoint.
NOTE: If you click Install while learning is in progress (in either manual or
automatic installation mode), it stops the learning process and prompts you for
confirmation that you want to stop learning and install the learned values.
Once you confirm, the learned values are automatically installed or prepared
for manual installation.
Setpoint learning parameters
Parameter Value/Range Description
Install mode Automatic,
Manual
• Automatic: the learned values are automatically
applied.
• Manual: the learned values are stored for you to
review and enter.
Duration 1-365 Days for maximum learning duration.
Implementing sag/swell limit learning using ION Setup
You can use ION Setup to implement voltage sag/swell learning, which analyzes your
power system and recommends settings.
NOTE: Your meter’s power system must be stable in order to learn valid sag/swell
limits.
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
3. Navigate to Alarming > Sag/Swell.
4. Select Voltage and click Learn.
NOTE: You can manually configure the limit values by selecting the parameter
and clicking Edit.
The Global Setpoint Learning screen is displayed.
5. Click Setup.
The Alarm Learning Setup screen is displayed.
6. Configure the sag/swell limit learning parameters and click Save.
162 7EN05-0336-03
