4 - 18
CSM-4 Connections and Ratings
NOTES
1. Use only listed solenoids from the following table:
noitacilppA
ekaMledoM
#mumixaM
4-MOMrep
31APFN
noitcA-erP(
)eguleD
rennikSV42,52XBL2VL5
OCSAV42,701A012BT5
OCSAV42,701A0128R5
OCSAV42,701A01285
A21APFN
)nolaH(
oryPV42,136289-0058
oryPV42,256682-0058
oryPV42,773380-0058
oryPV42,929680-0058
1002APFN
)002-MF(
oryPPXE42-SHCE8
2. Solenoids supervised for opens only.
3. Polarity shown in supervisory condition.
4. Releasing circuits are not power limited.
5. No end of line device used.
6. Each MOM-4 must be powered from a separate
ALARM-SAF power supply.
7. Set all positions of S2 on the CSM-4 to OFF (OPEN).
MXL Releasing Service Wiring (per NFPA 12A, NFPA 13, and NFPA 2001)
Technical Manuals Online! - http://www.tech-man.com
